Commercial Slab Repair, Concrete Restoration & Grouting in NC & SC

At Carolina Foundation Solutions, we offer the full array of concrete slab foundation repair services for commercial properties. We know that different slabs will have different issues and needs, which is why we’re ready to provide the best-fit option to restore commercial concrete slabs. This includes:

• Pressure grouting
• Polyurethane foam injection
• The installation of carbon fiber reinforcement
• The installation of helical piles
• Joint stabilization
• Epoxy injection

Here’s a closer look at some of these options and when one may be a better solution than others.

Contact Carolina Foundation Solutions at (877) 770-7050 for commercial slab repair service in the Carolinas.

Concrete Slab Lifting & Leveling

Concrete is a very strong, durable, reliable material. However, concrete slabs and concrete structures are not immune to problems that may require repairs. These problems, like settling and cracking in concrete slabs, can often occur as a result of movement or issues within the underlying soils or substructure.

Carolina Foundation Solutions specializes in addressing these poor soil conditions, as well as repairing concrete slabs and structures that have settled. We are fully equipped and experienced at lifting, leveling, and stabilizing concrete slabs, including foundations supporting:

• Walkways, patios, and walls at office buildings
• Apartment complexes
• Industrial warehouses
• Retail spaces
• And more!

Concrete Crack & Joint Repairs

From structural cracks in a concrete slab to leaks and joint problems, Carolina Foundation Solutions can diagnose the issue and determine the best option for resolving it. Our concrete experts are experienced with the following techniques, which can give you confidence that we’re the team you can rely on for top-notch commercial slab repair whenever you need it:

• Stitch welding
• Injecting high-strength epoxy materials into slabs
• Applying durable joint sealants
• Injecting leak seal resins

Contact Carolina Foundation Solutions at (877) 770-7050 for commercial slab repair service in the Carolinas.

Concrete Slab Repair & Grouting Products by Carolina Foundation Solutions

Polyurethane Foam

Unstable soils, poorly compacted soils, eroded soils, and poor native soils can exist around and beneath infrastructures. These underlying soil conditions can eventually result in settlement and damage to the structures or items that rest upon them.

Carolina Foundation Solutions specializes in addressing poor soil conditions and repairing the foundations on them that have settled. The injection of polyurethane foam is an excellent solution for soil stabilization and concrete lifting, especially when sinkholes and voids exist.

We are a certified installer for Alchemy Polymers. Alchemy Polymers offers various high-strength products, including their:

• AP Lift series
• AP Soil series
• AP Seal series

The AP Lift product consists of a two-component polyurethane structural foam. This product line has been used in several applications, ranging from lifting sections of settled concrete sidewalks to supporting concrete railway slabs that are 4 feet thick.

Using the polyurethane foam, Carolina Foundation Solutions has successfully:

• Lifted concrete slabs of an apartment building that have settled
• Stabilized warehouse floors that were rocking due to slab curling
• Filled existing voids beneath transformer pads

Advantages of Alchemy Polymers Polyurethane Foam

• Low mobilization costs
• Fast installation
• Installation possible in nearly any weather conditions
• Lightweight material
• Immediate results
• Little to no mess

Therefore…

• There is no need to plan for the arrival of large equipment, like the concrete mixers that would be needed for cement-based grouting.
• There is no extended wait time, as required for the curing of cement-based grout.
• There is no need to wait for the perfect weather conditions.
• There is no need to prohibit traffic from the work area for an extended period.

Carolina Foundation Solutions also specializes in performing the polyurethane foam injection grouting procedure. Polyurethane foam injection grouting, a type of pressure grouting, is performed in a very similar manner to that of other grouting, but it:

• Creates less mess
• Requires less time for curing of the materials
• Can be done by drilling much smaller holes

After drilling holes through the concrete, we inject an Alchemy Polymers polyurethane foam product, which is a two-component, high-strength, hydro-insensitive structural polymer foam. The material is lightweight and provides immediate results.

The injected materials will fill any voids that may exist between the bottom of the concrete slab and the top of the soils. These materials will also:

• Consolidate loose and soft soils located along the upper layers of the underlying soils
• Create a more solid base that shall assist in preventing future movement
• Allow for the lifting of settled areas of the concrete slab

The injection of a cement-based grout is a widely used and well-known method of lifting concrete slabs that have settled. This procedure, which is often referred to as pressure grouting or slab jacking, can be a great alternative to replacing existing concrete slabs.

Carolina Foundation Solutions is equipped with multiple pumps, all of which are cutting-edge and versatile. With this powerful equipment and our extensive experience, we can efficiently perform various grouting procedures to fill voids and more.

Advantages of Cement-Based Grout

• Low mobilization costs
• Highly available material
• Several options for material strength and density

Epoxy Injection

There have been huge advancements within the technology of epoxy and sealant materials over the years. Due to the adhesive properties and the wide range of epoxy and sealant products available, there are many potential applications and uses.

Carolina Foundation Solutions has a great deal of experience with the injection and application of various epoxy and sealant products. Our portfolio includes:

• Injecting high-strength epoxy resin products for bonding cracks with concrete walls and concrete slabs
• Injecting epoxy sealants into cracks and joints of walls to prevent water intrusion
• Sealing existing joints within the concrete slabs of office buildings, warehouses, and other industrial facilities

Wherever severe cracks exist within concrete, requiring structural repairs, Carolina Foundation Solutions is more than capable of performing the epoxy stitch weld repairs. These repairs involve injecting a high-strength epoxy resin, along with “stitches” that are created along the length of the cracks. The “stitches” provide additional reinforcement and tensile strength, further bonding the severed concrete.

Unfortunately, settlement and movement within concrete may be a result of unstable conditions within the soils that lie deep below the surface.  When those conditions are present, the installation of helical piles with slab brackets is typically the most effective solution.  The helical piers transfer the weight of the concrete from the base of the slab down to a layer of suitable load bearing soils.
